Lens Holder - Lens Holder d32
Characteristics
- Holder for lenses and telecentric lights
- Robust mount for high mechanical loads
- Support long lenses for vibration-free attachment
- Fixation of the optical adjustment under extreme mechanical loads
- Adaptable to various attachment situations such as direct attachment to the machine frame, attachment to a separate rail with attachment features or combination of rail and machine
Technical data
| Material | Aluminium, black anodised |
| Weight | 53 g |
| Clamping diameter | 32 mm |
| Clamping length | 10 mm |
| Can be combined with: | |
| Telecentric optic | T24 series T51 series T107 series T125 series TOB11 series TOB22 series TOB42 series |
Drawings
Dimensional drawing in mm
