Title:
Short description:
area light, white, diffuse, lf-size: 240x180 mm, camera view, static
Order number:
1-15-872
EAN:
4251692655368
Actual Notice:
Not for new developments
Please use the products of the A-DIF or FDLRL series for new developments.
Please use the products of the A-DIF or FDLRL series for new developments.
Downloads:
Characteristics
- metal casing, optical material: PMMA
- homogeneous illumination
- lighting controller integrated in casing
- continuous or pulsed operation
- pulse-length and brightness adjustable
- connection: cable with open ends
- metal casing, optical material: glass
- multiple mounting options
Technical data
| Light-emitting surface | 240 mm x 180 mm |
| Light design | Diffus |
| Light colour (typ.) | White, 5700 K |
| Operating mode | Switchable continuous operation |
| Special feature | Brightness setting via analog control voltage 0 - 10 VDC (switchable 3 ms - ∞) or manually on the potentiometer |
| Operation voltage | 24 VDC (10 - 30 V) |
| Power consumption | max. 35 W (1.4 A at 24 VDC) |
| Radiance | 10.1 W/m²sr |
| Luminance | 2,958 cd/m² |
| Housing material | Aluminium, black anodised |
| Optical material | Glass |
| Weight | 2,400 g |
| Degree of protection | IP50 |
| Safety class | Class III, safety extra low voltage (SELV) |
| Risk group (DIN EN 62471) | Freie Gruppe |
| Ambient temperature | - 10 °C ... + 45 °C |
| Cable | |
| Cable length | 1,500 mm |
| Cable diameter | 6.5 mm |
| Cable structure | 4 x 0.25 mm² and 3 x 0.5 mm² |
| Drag chain suitable | yes |
Notices
For further information, please contact your personal contact in our sales department.
Drawings
Dimensional drawing in mm
Pin assignment: cable open, 4-core
Title:
Short description:
area light, IR850, diffuse, lf-size: 240x180 mm, camera view, static
Order number:
1-15-841
EAN:
4251692655290
Actual Notice:
Not for new developments
Please use the products of the A-DIF or FDLRL series for new developments.
Please use the products of the A-DIF or FDLRL series for new developments.
Downloads:
Characteristics
- metal casing, optical material: PMMA
- homogeneous illumination
- lighting controller integrated in casing
- continuous or pulsed operation
- pulse-length and brightness adjustable
- connection: cable with open ends
- metal casing, optical material: glass
- multiple mounting options
Technical data
| Light-emitting surface | 240 mm x 180 mm |
| Light design | Diffus |
| Light colour (typ.) | Infrared, 850 nm |
| Operating mode | Switchable continuous operation |
| Special feature | Brightness setting via analog control voltage 0 - 10 VDC (switchable 3 ms - ∞) or manually on the potentiometer |
| Operation voltage | 24 VDC (10 - 30 V) |
| Power consumption | max. 35 W (1.4 A at 24 VDC) |
| Radiance | 31.7 W/(m²sr) |
| Luminance | - |
| Housing material | Aluminium, black anodised |
| Optical material | Glass |
| Weight | 2,400 g |
| Degree of protection | IP50 |
| Safety class | Class III, safety extra low voltage (SELV) |
| Risk group (DIN EN 62471) | Freie Gruppe |
| Ambient temperature | - 10 °C ... + 45 °C |
| Cable | |
| Cable length | 1,500 mm |
| Cable diameter | 6.5 mm |
| Cable structure | 4 x 0.25 mm² and 3 x 0.5 mm² |
| Drag chain suitable | yes |
Notices
For further information, please contact your personal contact in our sales department.
Drawings
Dimensional drawing in mm
Pin assignment: cable open, 4-core
Title:
Short description:
area light, red, diffuse, lf-size: 240x180 mm, camera view, static
Order number:
1-15-866
EAN:
4251692655344
Actual Notice:
Not for new developments
Please use the products of the A-DIF or FDLRL series for new developments.
Please use the products of the A-DIF or FDLRL series for new developments.
Downloads:
Characteristics
- metal casing, optical material: PMMA
- homogeneous illumination
- lighting controller integrated in casing
- continuous or pulsed operation
- pulse-length and brightness adjustable
- connection: cable with open ends
- metal casing, optical material: glass
- multiple mounting options
Technical data
| Light-emitting surface | 240 mm x 180 mm |
| Light design | Diffus |
| Light colour (typ.) | Red, 633 nm |
| Operating mode | Switchable continuous operation |
| Special feature | Brightness setting via analog control voltage 0 - 10 VDC (switchable 3 ms - ∞) or manually on the potentiometer |
| Operation voltage | 24 VDC (10 - 30 V) |
| Power consumption | max. 35 W (1.4 A at 24 VDC) |
| Radiance | 14.6 W/m²sr |
| Luminance | 1,920 cd/m² |
| Housing material | Aluminium, black anodised |
| Optical material | Glass |
| Weight | 2,400 g |
| Degree of protection | IP50 |
| Safety class | Class III, safety extra low voltage (SELV) |
| Risk group (DIN EN 62471) | Freie Gruppe |
| Ambient temperature | - 10 °C ... + 45 °C |
| Cable | |
| Cable length | 1,500 mm |
| Cable diameter | 6.5 mm |
| Cable structure | 4 x 0.25 mm² and 3 x 0.5 mm² |
| Drag chain suitable | yes |
Notices
For further information, please contact your personal contact in our sales department.
Drawings
Dimensional drawing in mm
Pin assignment: cable open, 4-core
Title:
Short description:
area light, blue, directed, lf-size: 50mmx40mm, smart light
Order number:
1-33-082
Actual Notice:
coming soon
Downloads:
Characteristics
- Power-LED area light
- currently our brightest area lighting
- high Radiant Efficiency (up to 72 %)
- vicolux® smart light - Technology
- safe operation due to vicolux® smart light Controller (e.g. DLC3005)
- connection: M8 plug on the casing
- metal casing, plane rear wall for optimal heat dissipation
- Heat sink available as option
- multiple mounting options
- mechanically compatible with the FAL60x90 series
Technical data
| Light-emitting surface | 50 mm x 40 mm |
| Light colour | Blue, 450 nm |
| Light design | gerichtet |
| Special feature | Flashable with flash controller |
| Power consumption | |
| Irradiance ¹) | |
| Radiance | |
| Housing material | Aluminium, black anodised |
| Optical material | PMMA |
| Weight | 100 g |
| Degree of protection | IP50 |
| Safety class | Class III, safety extra low voltage (SELV) |
| Ambient temperature | -10 °C ... +55 °C |
| ¹) working distance = 100 mm |
Notices
The lighting can only be operated in conjunction with a lighting controller or a suitable current source.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
Can be combined with
Accessories
| Order number | Title | Description |
|---|---|---|
| Connection cable M8-4pin | ||
| 1-11-611 | Cable-M8-4p-5A-straight-1m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-612 | Cable-M8-4p-5A-straight-2m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-613 | Cable-M8-4p-5A-straight-3m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-614 | Cable-M8-4p-5A-straight-5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-609 | Cable-M8-4p-4A-straight-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-605 | Cable-M8-4p-4A-angled-2m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| 1-11-604 | Cable-M8-4p-4A-angled-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| Extension cable M8-4pin | ||
| 1-11-093 | Extension cable-M8-4p-5A-0.6m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-094 | Extension cable-M8-4p-5A-1.5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-095 | Extension cable-M8-4p-5A-3.0m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
Title:
Short description:
area light, white, directed, lf-size: 50mmx40mm, smart light
Order number:
1-33-083
Actual Notice:
coming soon
Downloads:
Characteristics
- Power-LED area light
- currently our brightest area lighting
- vicolux® smart light - Technology
- safe operation due to vicolux® smart light Controller (e.g. DLC3005)
- connection: M8 plug on the casing
- metal casing, plane rear wall for optimal heat dissipation
- Heat sink available as option
- multiple mounting options
- mechanically compatible with the FAL60x90 series
Technical data
| Light-emitting surface | 50 mm x 40 mm |
| Light colour | White, 5700 K |
| Light design | Directed |
| Special feature | Flashable with flash controller |
| Power consumption | |
| Irradiance ¹) | |
| Radiance | |
| Housing material | Aluminium, black anodised |
| Optical material | PMMA |
| Weight | 100 g |
| Degree of protection | IP50 |
| Safety class | Class III, safety extra low voltage (SELV) |
| Ambient temperature | -10 °C ... +55 °C |
| ¹) working distance = 100 mm |
Notices
The lighting can only be operated in conjunction with a lighting controller or a suitable current source.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
Can be combined with
Accessories
| Order number | Title | Description |
|---|---|---|
| Connection cable M8-4pin | ||
| 1-11-611 | Cable-M8-4p-5A-straight-1m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-612 | Cable-M8-4p-5A-straight-2m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-613 | Cable-M8-4p-5A-straight-3m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-614 | Cable-M8-4p-5A-straight-5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-609 | Cable-M8-4p-4A-straight-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-605 | Cable-M8-4p-4A-angled-2m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| 1-11-604 | Cable-M8-4p-4A-angled-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| Extension cable M8-4pin | ||
| 1-11-093 | Extension cable-M8-4p-5A-0.6m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-094 | Extension cable-M8-4p-5A-1.5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-095 | Extension cable-M8-4p-5A-3.0m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
Title:
Short description:
area light, red, directed, lf-size: 50mmx40mm, smart light
Order number:
1-33-080
Actual Notice:
coming soon
Downloads:
Characteristics
- Power-LED area light
- currently our brightest area lighting
- vicolux® smart light - Technology
- safe operation due to vicolux® smart light Controller (e.g. DLC3005)
- connection: M8 plug on the casing
- metal casing, plane rear wall for optimal heat dissipation
- Heat sink available as option
- multiple mounting options
- mechanically compatible with the FAL60x90 series
Technical data
| Light-emitting surface | 50 mm x 40 mm |
| Light colour | Red, 633 nm |
| Light design | gerichtet |
| Special feature | Flashable with flash controller |
| Power consumption | |
| Irradiance ¹) | |
| Radiance | |
| Housing material | Aluminium, black anodised |
| Optical material | PMMA |
| Weight | 100 g |
| Degree of protection | IP50 |
| Safety class | Class III, safety extra low voltage (SELV) |
| Ambient temperature | -10 °C ... +55 °C |
| ¹) working distance = 100 mm |
Notices
The lighting can only be operated in conjunction with a lighting controller or a suitable current source.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
Can be combined with
Accessories
| Order number | Title | Description |
|---|---|---|
| Connection cable M8-4pin | ||
| 1-11-611 | Cable-M8-4p-5A-straight-1m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-612 | Cable-M8-4p-5A-straight-2m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-613 | Cable-M8-4p-5A-straight-3m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-614 | Cable-M8-4p-5A-straight-5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-609 | Cable-M8-4p-4A-straight-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-605 | Cable-M8-4p-4A-angled-2m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| 1-11-604 | Cable-M8-4p-4A-angled-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| Extension cable M8-4pin | ||
| 1-11-093 | Extension cable-M8-4p-5A-0.6m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-094 | Extension cable-M8-4p-5A-1.5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-095 | Extension cable-M8-4p-5A-3.0m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
Title:
Short description:
area light, green, directed, lf-size: 50mmx40mm, smart light
Order number:
1-33-081
Actual Notice:
coming soon
Downloads:
Characteristics
- Power-LED area light
- currently our brightest area lighting
- vicolux® smart light - Technology
- safe operation due to vicolux® smart light Controller (e.g. DLC3005)
- connection: M8 plug on the casing
- metal casing, plane rear wall for optimal heat dissipation
- Heat sink available as option
- multiple mounting options
- mechanically compatible with the FAL60x90 series
Technical data
| Light-emitting surface | 50 mm x 40 mm |
| Light colour | Grün, 525 nm |
| Light design | Directed |
| Special feature | Flashable with flash controller |
| Power consumption | |
| Irradiance ¹) | |
| Radiance | |
| Housing material | Aluminium, black anodised |
| Optical material | PMMA |
| Weight | 100 g |
| Degree of protection | IP50 |
| Safety class | Class III, safety extra low voltage (SELV) |
| Ambient temperature | -10 °C ... +55 °C |
| ¹) working distance = 100 mm |
Notices
The lighting can only be operated in conjunction with a lighting controller or a suitable current source.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
Can be combined with
Accessories
| Order number | Title | Description |
|---|---|---|
| Connection cable M8-4pin | ||
| 1-11-611 | Cable-M8-4p-5A-straight-1m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-612 | Cable-M8-4p-5A-straight-2m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-613 | Cable-M8-4p-5A-straight-3m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-614 | Cable-M8-4p-5A-straight-5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-609 | Cable-M8-4p-4A-straight-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-605 | Cable-M8-4p-4A-angled-2m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| 1-11-604 | Cable-M8-4p-4A-angled-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| Extension cable M8-4pin | ||
| 1-11-093 | Extension cable-M8-4p-5A-0.6m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-094 | Extension cable-M8-4p-5A-1.5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-095 | Extension cable-M8-4p-5A-3.0m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
Title:
Short description:
area light, IR, directed, lf-size: 50mmx40mm, smart light
Order number:
1-33-084
Actual Notice:
coming soon
Downloads:
Characteristics
- Power-LED area light
- currently our brightest area lighting
- vicolux® smart light - Technology
- safe operation due to vicolux® smart light Controller (e.g. DLC3005)
- connection: M8 plug on the casing
- metal casing, plane rear wall for optimal heat dissipation
- Heat sink available as option
- multiple mounting options
- mechanically compatible with the FAL60x90 series
Technical data
| Light-emitting surface | 50 mm x 40 mm |
| Light colour | Infrared, 850 nm |
| Light design | gerichtet |
| Special feature | Flashable with flash controller |
| Power consumption | |
| Irradiance ¹) | |
| Radiance | |
| Housing material | Aluminium, black anodised |
| Optical material | PMMA |
| Weight | 100 g |
| Degree of protection | IP50 |
| Safety class | Class III, safety extra low voltage (SELV) |
| Ambient temperature | -10 °C ... +55 °C |
| ¹) working distance = 100 mm |
Notices
The lighting can only be operated in conjunction with a lighting controller or a suitable current source.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
Can be combined with
Accessories
| Order number | Title | Description |
|---|---|---|
| Connection cable M8-4pin | ||
| 1-11-611 | Cable-M8-4p-5A-straight-1m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-612 | Cable-M8-4p-5A-straight-2m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-613 | Cable-M8-4p-5A-straight-3m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-614 | Cable-M8-4p-5A-straight-5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-609 | Cable-M8-4p-4A-straight-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-605 | Cable-M8-4p-4A-angled-2m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| 1-11-604 | Cable-M8-4p-4A-angled-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| Extension cable M8-4pin | ||
| 1-11-093 | Extension cable-M8-4p-5A-0.6m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-094 | Extension cable-M8-4p-5A-1.5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-095 | Extension cable-M8-4p-5A-3.0m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
Title:
Short description:
area light, IR940, directed, lf-size: 50mmx40mm, smart light
Order number:
1-33-085
Actual Notice:
coming soon
Downloads:
Characteristics
- Power-LED area light
- currently our brightest area lighting
- vicolux® smart light - Technology
- safe operation due to vicolux® smart light Controller (e.g. DLC3005)
- connection: M8 plug on the casing
- metal casing, plane rear wall for optimal heat dissipation
- Heat sink available as option
- multiple mounting options
- mechanically compatible with the FAL60x90 series
Technical data
| Light-emitting surface | 50 mm x 40 mm |
| Light colour | Infrarot, 940 nm |
| Light design | Directed |
| Special feature | Flashable with flash controller |
| Power consumption | |
| Irradiance ¹) | |
| Radiance | |
| Housing material | Aluminium, black anodised |
| Optical material | PMMA |
| Weight | 100 g |
| Degree of protection | IP50 |
| Safety class | Class III, safety extra low voltage (SELV) |
| Ambient temperature | -10 °C ... +55 °C |
| ¹) working distance = 100 mm |
Notices
The lighting can only be operated in conjunction with a lighting controller or a suitable current source.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
Can be combined with
Accessories
| Order number | Title | Description |
|---|---|---|
| Connection cable M8-4pin | ||
| 1-11-611 | Cable-M8-4p-5A-straight-1m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-612 | Cable-M8-4p-5A-straight-2m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-613 | Cable-M8-4p-5A-straight-3m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-614 | Cable-M8-4p-5A-straight-5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-609 | Cable-M8-4p-4A-straight-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-605 | Cable-M8-4p-4A-angled-2m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| 1-11-604 | Cable-M8-4p-4A-angled-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| Extension cable M8-4pin | ||
| 1-11-093 | Extension cable-M8-4p-5A-0.6m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-094 | Extension cable-M8-4p-5A-1.5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-095 | Extension cable-M8-4p-5A-3.0m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
Title:
Short description:
area light, IR1050, directed, lf-size: 50mmx40mm, smart light
Order number:
1-33-086
Actual Notice:
coming soon
Downloads:
Characteristics
- Power-LED area light
- currently our brightest area lighting
- vicolux® smart light - Technology
- safe operation due to vicolux® smart light Controller (e.g. DLC3005)
- connection: M8 plug on the casing
- metal casing, plane rear wall for optimal heat dissipation
- Heat sink available as option
- multiple mounting options
- mechanically compatible with the FAL60x90 series
Technical data
| Light-emitting surface | 50 mm x 40 mm |
| Light colour | Infrarot, 1050 nm |
| Light design | gerichtet |
| Special feature | Flashable with flash controller |
| Power consumption | |
| Irradiance ¹) | |
| Radiance | |
| Housing material | Aluminium, black anodised |
| Optical material | PMMA |
| Weight | 100 g |
| Degree of protection | IP50 |
| Safety class | Class III, safety extra low voltage (SELV) |
| Ambient temperature | -10 °C ... +55 °C |
| ¹) working distance = 100 mm |
Notices
The lighting can only be operated in conjunction with a lighting controller or a suitable current source.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
Can be combined with
Accessories
| Order number | Title | Description |
|---|---|---|
| Connection cable M8-4pin | ||
| 1-11-611 | Cable-M8-4p-5A-straight-1m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-612 | Cable-M8-4p-5A-straight-2m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-613 | Cable-M8-4p-5A-straight-3m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-614 | Cable-M8-4p-5A-straight-5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-609 | Cable-M8-4p-4A-straight-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-605 | Cable-M8-4p-4A-angled-2m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| 1-11-604 | Cable-M8-4p-4A-angled-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| Extension cable M8-4pin | ||
| 1-11-093 | Extension cable-M8-4p-5A-0.6m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-094 | Extension cable-M8-4p-5A-1.5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-095 | Extension cable-M8-4p-5A-3.0m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
Title:
Short description:
area light, blue, directed, lf-size: 50mmx80mm, P-LED, smart light
Order number:
1-33-057
EAN:
4251692652022
Downloads:
Characteristics
- Power-LED area light
- currently our brightest area lighting
- high Radiant Efficiency (up to 72 %)
- vicolux® smart light - Technology
- safe operation due to vicolux® smart light Controller (e.g. DLC3005)
- connection: M8 plug on the casing
- metal casing, plane rear wall for optimal heat dissipation
- Heat sink available as option
- multiple mounting options
- mechanically compatible with the FAL60x90 series
Technical data
| Light-emitting surface | 50 mm x 80 mm |
| Light colour | Blue, 450 nm |
| Light design | Directed |
| Special feature | Flashable with flash controller |
| Power consumption | |
| • Continuous operation | 15.0 W |
| • Flash mode | 15.0 W |
| Irradiance ¹) | |
| • Continuous operation | 3,400 W/m² |
| • Flash mode | 11,800 W/m² |
| Radiance | |
| Housing material | Aluminium, black anodised |
| Optical material | PMMA |
| Weight | 130 g |
| Degree of protection | IP50 |
| Safety class | Class III, safety extra low voltage (SELV) |
| Ambient temperature | -10 °C ... +55 °C |
| ¹) working distance = 100 mm |
Notices
The lighting can only be operated in conjunction with a lighting controller or a suitable current source.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
Drawings
Dimensional drawing in mm
Pin assignment: M8 connector
Can be combined with
Accessories
| Order number | Title | Description |
|---|---|---|
| Connection cable M8-4pin | ||
| 1-11-611 | Cable-M8-4p-5A-straight-1m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-612 | Cable-M8-4p-5A-straight-2m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-613 | Cable-M8-4p-5A-straight-3m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-614 | Cable-M8-4p-5A-straight-5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-609 | Cable-M8-4p-4A-straight-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-605 | Cable-M8-4p-4A-angled-2m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| 1-11-604 | Cable-M8-4p-4A-angled-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| Extension cable M8-4pin | ||
| 1-11-093 | Extension cable-M8-4p-5A-0.6m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-094 | Extension cable-M8-4p-5A-1.5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-095 | Extension cable-M8-4p-5A-3.0m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
Title:
Short description:
area light, white, directed, lf-size: 50mmx80mm, P-LED, smart light
Order number:
1-33-058
EAN:
4251692652039
Downloads:
Characteristics
- Power-LED area light
- currently our brightest area lighting
- vicolux® smart light - Technology
- safe operation due to vicolux® smart light Controller (e.g. DLC3005)
- connection: M8 plug on the casing
- metal casing, plane rear wall for optimal heat dissipation
- Heat sink available as option
- multiple mounting options
- mechanically compatible with the FAL60x90 series
Technical data
| Light-emitting surface | 50 mm x 80 mm |
| Light colour | White, 5700 K |
| Light design | gerichtet |
| Special feature | Flashable with flash controller |
| Power consumption | |
| • Continuous operation | 15.0 W |
| • Flash mode | 15.0 W |
| Irradiance ¹) | |
| • Continuous operation | 2,500 W/m² |
| • Flash mode | 8,300 W/m² |
| Radiance | |
| Housing material | Aluminium, black anodised |
| Optical material | PMMA |
| Weight | 130 g |
| Degree of protection | IP50 |
| Safety class | Class III, safety extra low voltage (SELV) |
| Ambient temperature | -10 °C ... +55 °C |
| ¹) working distance = 100 mm |
Notices
The lighting can only be operated in conjunction with a lighting controller or a suitable current source.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
Drawings
Dimensional drawing in mm
Pin assignment: M8 connector
Can be combined with
Accessories
| Order number | Title | Description |
|---|---|---|
| Connection cable M8-4pin | ||
| 1-11-611 | Cable-M8-4p-5A-straight-1m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-612 | Cable-M8-4p-5A-straight-2m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-613 | Cable-M8-4p-5A-straight-3m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-614 | Cable-M8-4p-5A-straight-5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-609 | Cable-M8-4p-4A-straight-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-605 | Cable-M8-4p-4A-angled-2m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| 1-11-604 | Cable-M8-4p-4A-angled-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| Extension cable M8-4pin | ||
| 1-11-093 | Extension cable-M8-4p-5A-0.6m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-094 | Extension cable-M8-4p-5A-1.5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-095 | Extension cable-M8-4p-5A-3.0m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
Title:
Short description:
area light, red, directed, lf-size: 50mmx80mm, P-LED, smart light
Order number:
1-33-055
EAN:
4251692652008
Downloads:
Characteristics
- Power-LED area light
- currently our brightest area lighting
- vicolux® smart light - Technology
- safe operation due to vicolux® smart light Controller (e.g. DLC3005)
- connection: M8 plug on the casing
- metal casing, plane rear wall for optimal heat dissipation
- Heat sink available as option
- multiple mounting options
- mechanically compatible with the FAL60x90 series
Technical data
| Light-emitting surface | 50 mm x 80 mm |
| Light colour | Rot, 633 nm |
| Light design | Directed |
| Special feature | Flashable with flash controller |
| Power consumption | |
| • Continuous operation | 15.0 W |
| • Flash mode | 15.0 W |
| Irradiance ¹) | |
| • Continuous operation | 2.300 W/m² |
| • Flash mode | 8,500 W/m² |
| Radiance | |
| Housing material | Aluminium, black anodised |
| Optical material | PMMA |
| Weight | 130 g |
| Degree of protection | IP50 |
| Safety class | Class III, safety extra low voltage (SELV) |
| Ambient temperature | -10 °C ... +55 °C |
| ¹) working distance = 100 mm |
Notices
The lighting can only be operated in conjunction with a lighting controller or a suitable current source.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
Drawings
Dimensional drawing in mm
Pin assignment: M8 connector
Can be combined with
Accessories
| Order number | Title | Description |
|---|---|---|
| Connection cable M8-4pin | ||
| 1-11-611 | Cable-M8-4p-5A-straight-1m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-612 | Cable-M8-4p-5A-straight-2m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-613 | Cable-M8-4p-5A-straight-3m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-614 | Cable-M8-4p-5A-straight-5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-609 | Cable-M8-4p-4A-straight-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-605 | Cable-M8-4p-4A-angled-2m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| 1-11-604 | Cable-M8-4p-4A-angled-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| Extension cable M8-4pin | ||
| 1-11-093 | Extension cable-M8-4p-5A-0.6m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-094 | Extension cable-M8-4p-5A-1.5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-095 | Extension cable-M8-4p-5A-3.0m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
Title:
Short description:
area light, green, directed, lf-size: 50mmx80mm, P-LED, smart light
Order number:
1-33-056
EAN:
4251692652015
Downloads:
Characteristics
- Power-LED area light
- currently our brightest area lighting
- vicolux® smart light - Technology
- safe operation due to vicolux® smart light Controller (e.g. DLC3005)
- connection: M8 plug on the casing
- metal casing, plane rear wall for optimal heat dissipation
- Heat sink available as option
- multiple mounting options
- mechanically compatible with the FAL60x90 series
Technical data
| Light-emitting surface | 50 mm x 80 mm |
| Light colour | Grün, 525 nm |
| Light design | gerichtet |
| Special feature | Flashable with flash controller |
| Power consumption | |
| • Continuous operation | 15.0 W |
| • Flash mode | 15.0 W |
| Irradiance ¹) | |
| • Continuous operation | 1.000 W/m² |
| • Flash mode | 3,200 W/m² |
| Radiance | |
| Housing material | Aluminium, black anodised |
| Optical material | PMMA |
| Weight | 130 g |
| Degree of protection | IP50 |
| Safety class | Class III, safety extra low voltage (SELV) |
| Risk group (DIN EN 62471) | Risk group 1 |
| Ambient temperature | -10 °C ... +55 °C |
| ¹) working distance = 100 mm |
Notices
The lighting can only be operated in conjunction with a lighting controller or a suitable current source.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
Drawings
Dimensional drawing in mm
Pin assignment: M8 connector
Can be combined with
Accessories
| Order number | Title | Description |
|---|---|---|
| Connection cable M8-4pin | ||
| 1-11-611 | Cable-M8-4p-5A-straight-1m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-612 | Cable-M8-4p-5A-straight-2m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-613 | Cable-M8-4p-5A-straight-3m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-614 | Cable-M8-4p-5A-straight-5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-609 | Cable-M8-4p-4A-straight-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-605 | Cable-M8-4p-4A-angled-2m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| 1-11-604 | Cable-M8-4p-4A-angled-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| Extension cable M8-4pin | ||
| 1-11-093 | Extension cable-M8-4p-5A-0.6m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-094 | Extension cable-M8-4p-5A-1.5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-095 | Extension cable-M8-4p-5A-3.0m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
Title:
Short description:
area light, IR850, directed, lf-size: 50mmx80mm, P-LED, smart light
Order number:
1-33-059
EAN:
4251692652046
Downloads:
Characteristics
- Power-LED area light
- currently our brightest area lighting
- vicolux® smart light - Technology
- safe operation due to vicolux® smart light Controller (e.g. DLC3005)
- connection: M8 plug on the casing
- metal casing, plane rear wall for optimal heat dissipation
- Heat sink available as option
- multiple mounting options
- mechanically compatible with the FAL60x90 series
Technical data
| Light-emitting surface | 50 mm x 80 mm |
| Light colour | Infrared, 850 nm |
| Light design | Directed |
| Special feature | Flashable with flash controller |
| Power consumption | |
| • Continuous operation | 15.0 W |
| • Flash mode | 15.0 W |
| Irradiance ¹) | |
| • Continuous operation | 2,100 W/m² |
| • Flash mode | 9,200 W/m² |
| Radiance | |
| Housing material | Aluminium, black anodised |
| Optical material | PMMA |
| Weight | 130 g |
| Degree of protection | IP50 |
| Safety class | Class III, safety extra low voltage (SELV) |
| Risk group (DIN EN 62471) | Risk group 1 |
| Ambient temperature | -10 °C ... +55 °C |
| ¹) working distance = 100 mm |
Notices
The lighting can only be operated in conjunction with a lighting controller or a suitable current source.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
vicolux® smart light lighting controllers limit the electrical parameters automatically and also monitor the temperature of the device.
Drawings
Dimensional drawing in mm
Pin assignment: M8 connector
Can be combined with
Accessories
| Order number | Title | Description |
|---|---|---|
| Connection cable M8-4pin | ||
| 1-11-611 | Cable-M8-4p-5A-straight-1m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-612 | Cable-M8-4p-5A-straight-2m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-613 | Cable-M8-4p-5A-straight-3m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-614 | Cable-M8-4p-5A-straight-5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-609 | Cable-M8-4p-4A-straight-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin straight socket to free cable end |
| 1-11-605 | Cable-M8-4p-4A-angled-2m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| 1-11-604 | Cable-M8-4p-4A-angled-5m | 4x0.25mm², 4A, 60V, PUR, IP67, M8-4pin angled socket to free cable end |
| Extension cable M8-4pin | ||
| 1-11-093 | Extension cable-M8-4p-5A-0.6m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-094 | Extension cable-M8-4p-5A-1.5m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
| 1-11-095 | Extension cable-M8-4p-5A-3.0m | 4x0.5mm², 5A, 30V, PUR, IP67, M8-4pin straight socket to M8-4pin straight plug |
Load more products..
